Excavator Grab Rotating Saw Log Grapple
ROTATING SAW LOG GRAPPLE

Excavator Grab Rotating Saw Log Grapple
ROTATING SAW LOG GRAPPLE

Available for 1.5t - 25t

EFFICIENT
RELIABLE
AFFORDABLE

The Rotating Saw Log Grapple is an essential attachment for tree handling and felling. The single log design allows the operator to accurately grab and cut entire trees and sort them accordingly, and the ability to trim and grab large branches directly from the tree itself.

The Rotating Saw Log Grapple is an essential attachment for tree handling and felling. The single log design allows the operator to accurately grab and cut tree logs and sort them accordingly, with the ability to grab large branches directly from the tree itself.

New call-to-action

AG &
FORESTRY

Excavator Grab Rotating Saw Log Grapple



BULK MATERIAL HANDLING

Excavator Grab Rotating Saw Log Grapple

New call-to-action

Excavator Grab Rotating Saw Log Grapple Excavator Grab Rotating Saw Log Grapple Excavator Grab Rotating Saw Log Grapple Excavator Grab Rotating Saw Log Grapple

Available for 1.5t - 25t

Excavator Grab Rotating Saw Log Grapple



New call-to-action



1

DURABILITY

The Rotating Grapple Saw is lightweight but strong where needed most to ensure a long attachment lifetime.

2

CONTROL HANDLE SYSTEM

It is equipped with imported solenoid valves, which can control the rotation speed, making it an easy-to-use attachment for beginner operators.

3

360° ROTATION

The Grapple Saws 360° rotation gives the attachment the flexibility and accuracy required to reach logs and branches in the most challenging environments quickly and efficiently.
4

INCREASE PRODUCTIVITY

Save a significant amount of time when felling to work through larger areas of forestry and bush in a much shorter timeframe.

5

WIDE OPENING

With one of the enormous width openings possible with a log grab, confidently handle whatever comes your way.
6

GRIP STRENGTH

High closing pressures make gripping the more minor, single logs easy and save you time by not having to switch to different grapples.
7

PIN QUALITY

It is made of 1045 high-quality carbon steel that has undergone quenching and tempering, ensuring long-term integrity.
8

WARRANTY YOU CAN TRUST

5 Year warranty and lifetime after-sales support with our entire range!



New call-to-action



Rotating Saw Log Grapple

Watch The Detailed Walkaround



EFFICIENT

Easily and quickly cut down trees or branches and move the material without the need to stop the machine and switch over attachments, giving you less downtime for your machine and speeding up time spent on the job.

Excavator Grab Rotating Saw Log Grapple


RELIABLE

Using BIS 400 steel plating the Rotating Saw Log Grapple is as light as a feather but as strong as an Ox, with unmatched abrasion resistance where it's the needed most, meaning you can rely on this attachment time and time again.

Excavator Grab Rotating Saw Log Grapple


AFFORDABLE

We supply the best gear on the market, for the best price. With our industry-leading 5 year warranty and affordable pricing, you can be certain you're always getting a bargain with Aussie Buckets.

Excavator Grab Rotating Saw Log Grapple


CLICK FOR QUOTE

Interested in our Rotating Saw Log Grapple? Hit our 'Quick Quote' button below to complete our form in 30 seconds or less to receive your custom quote today!

New call-to-action

Excavator Grab Rotating Saw Log Grapple

Specifications

  • 1.5-5t
    Name
    ROTATING SAW LOG GRAPPLE (1.5-5t)
    MIN HOLDING DIAMETER
    20±5mm
    MAX OPENING
    930±50mm
    MAX CUTTING DIAMTER
    270±20mm
    BAR OIL TANK CAPACITY
    1.5L
    WORKING PRESSURE
    21-26MPa
    MOTOR PRESSURE
    21-26MPa
    MOTOR FLOW RATE
    60L/min
    SAW LENGTH
    755mm
    WEIGHT
    290kg
    MODEL
    ABRLS - 290
    More Info
    Quick Quote
  • 6-9t
    Name
    ROTATING SAW LOG GRAPPLE (6-9t)
    MIN HOLDING DIAMETER
    60±5mm
    MAX OPENING
    1450±20mm
    MAX CUTTING DIAMTER
    550±20mm
    BAR OIL TANK CAPACITY
    2.7L
    WORKING PRESSURE
    21-26MPa
    MOTOR PRESSURE
    21-26MPa
    MOTOR FLOW RATE
    60L/min
    SAW LENGTH
    755mm
    WEIGHT
    514kg
    MODEL
    ABRLS - 514
    More Info
    Quick Quote
  • 7-17t
    Name
    ROTATING SAW LOG GRAPPLE (7-17t)
    MIN HOLDING DIAMETER
    70±5mm
    MAX OPENING
    1500±20mm
    MAX CUTTING DIAMTER
    500±20mm
    BAR OIL TANK CAPACITY
    2L
    WORKING PRESSURE
    21-26MPa
    MOTOR PRESSURE
    21-26MPa
    MOTOR FLOW RATE
    120L/min
    SAW LENGTH
    755mm
    WEIGHT
    687kg
    MODEL
    ABRLS - 687
    More Info
    Quick Quote
  • 18-25t
    Name
    ROTATING SAW LOG GRAPPLE (18-25t)
    MIN HOLDING DIAMETER
    110±30mm
    MAX OPENING
    2157±50mm
    MAX CUTTING DIAMTER
    80±30mm
    BAR OIL TANK CAPACITY
    2.7L
    WORKING PRESSURE
    21-26MPa
    MOTOR PRESSURE
    21-26MPa
    MOTOR FLOW RATE
    120L/min
    SAW LENGTH
    755mm
    WEIGHT
    1193kg
    MODEL
    ABRLS - 1193
    More Info
    Quick Quote
