Excavator Grab Rotating Light Duty Multipurpose Grab
ROTATING LIGHT DUTY MULTIPURPOSE GRAB

Excavator Grab Rotating Light Duty Multipurpose Grab
ROTATING LIGHT DUTY MULTIPURPOSE GRAB

available for 5t - 9t

AFFORDABLE
EASY TO USE
LIGHTWEIGHT

Our light-duty design with interlocking fingers, extreme closing pressures and 360-degree hydraulic rotation, this grab ensures minimal load loss with a low barrier to entry to begin capitalising on the benefits of a dedicated grab.

Our light-duty design with interlocking fingers, extreme closing pressures and 360-degree hydraulic rotation, this grab ensures minimal load loss with a low barrier to entry to begin capitalising on the benefits of a dedicated grab.

New call-to-action

New call-to-action

AG &
FORESTRY

Excavator Grab Rotating Light Duty Multipurpose Grab

RE-
CYCLING

Excavator Grab Rotating Light Duty Multipurpose Grab



BULK MATERIAL HANDLING

Excavator Grab Rotating Light Duty Multipurpose Grab

DEMO-
LITION

Excavator Grab Rotating Light Duty Multipurpose Grab
Excavator Grab Rotating Light Duty Multipurpose Grab Excavator Grab Rotating Light Duty Multipurpose Grab Excavator Grab Rotating Light Duty Multipurpose Grab Excavator Grab Rotating Light Duty Multipurpose Grab

available for 5t - 9t

Excavator Grab Rotating Light Duty Multipurpose Grab



New call-to-action



1

360° Rotation

Increase productivity and efficiency by utilizing 360-degree hydraulic rotation, maximizing accuracy and visibility for the operator.

2

5-Finger Interlocking Design

The 5-finger interlocking design gives the grab versatility to pick up both large and small materials whilst keeping a firm grip; minimizing load loss, and increasing productivity.

3

High-Grade Steel

Hydraulic Grapples are manufactured around properties of strength and abrasion resistance. High-grade reinforcements plates and components act to increase the sturdiness and durability of the attachment.
4

Affordable

The sturdy but lightweight design makes this grab ideal for operators looking for an affordable option, such as farm operators.

5

Reinforced welds

Weld quality guaranteed by ultrasonic testing ensures no microscopic discontinuities, differentiating us from other suppliers.
6

warranty you can trust

5 Year warranty and lifetime after-sales support with our entire range!



New call-to-action





AFFORDABLE

Our Rotating Light Duty Multipurpose Grab is a perfect choice for a single machine owner operator that just needs something for a couple of odd jobs around the farm.

Excavator Grab Rotating Light Duty Multipurpose Grab


EASY TO USE

The 5-finger interlocking design paired with extreme closing pressures makes this grab perfect for beginner operators with no experience using a grab before.

Excavator Grab Rotating Light Duty Multipurpose Grab


Lightweight

The lightweight design keeps the machine running and performing at optimal capacity, meaning you can grab larger loads at once without the need to worry if your machine can handle the weight.

Excavator Grab Rotating Light Duty Multipurpose Grab


CLICK FOR QUOTE

Interested in our Rotating Light Duty Multipurpose Grab? Hit our 'Quick Quote' button below to complete our form in 30 seconds or less to receive your custom quote today!

New call-to-action

Excavator Grab Rotating Light Duty Multipurpose Grab

Specifications

  • 5-9t
    Name
    ROTATING LIGHT DUTY MULTIPURPOSE GRAB (5-9t)
    CLOSE HEIGHT
    1273mm
    OPEN HEIGHT
    1296mm
    WIDTH CLAM (INNER/OUTER)
    (415/700) mm
    MAX OPENING
    1325±20mm
    MIN GRIP
    ≤Φ110mm
    MAX GRIP
    ≤Φ500mm
    WEIGHT
    380kg
    ROTATION TYPE
    External mesh vertical
    MODULE / DIAMETER
    M5/224mm
    MOTOR TYPE
    Cycloid motor
    MOTOR PRESSURE
    16MPa
    MOTOR FLOW RATE
    44.1L/min
    ROD DIAMETER
    Φ45
    BORE SIZE
    Φ80
    PRESSURE
    21MPa
    CYLINDER FLOW RATE
    33.3L/min
    MODEL
    ABRLDMG - 380
    More Info
    Quick Quote
  • 10-15t
    Name
    ROTATING LIGHT DUTY MULTIPURPOSE GRAB (10-15t)
    CLOSE HEIGHT
    1519mm
    OPEN HEIGHT
    1581mm
    WIDTH CLAM (INNER/OUTER)
    (415/700) mm
    MAX OPENING
    1450±20mm
    MIN GRIP
    ≤Φ135mm
    MAX GRIP
    ≤Φ560mm
    WEIGHT
    550kg
    ROTATION TYPE
    External mesh vertical
    MODULE / DIAMETER
    M5/315mm
    MOTOR TYPE
    Cycloid motor
    MOTOR PRESSURE
    16MPa
    MOTOR FLOW RATE
    51.7L/min
    ROD DIAMETER
    Φ50
    BORE SIZE
    Φ90
    PRESSURE
    21MPa
    CYLINDER FLOW RATE
    47.7L/min
    MODEL
    ABRLDMG - 550
    More Info
    Get our Brochure

LIGHT DUTY MULTIPURPOSE GRAB
APPLICATIONS

Excavator Grab Rotating Light Duty Multipurpose Grab Excavator Grab Rotating Light Duty Multipurpose Grab Excavator Grab Rotating Light Duty Multipurpose Grab Excavator Grab Rotating Light Duty Multipurpose Grab Excavator Grab Rotating Light Duty Multipurpose Grab

Excavator Grab Rotating Light Duty Multipurpose Grab

LIGHT DUTY MULTIPURPOSE GRAB
APPLICATIONS

Excavator Grab Rotating Light Duty Multipurpose Grab Excavator Grab Rotating Light Duty Multipurpose Grab Excavator Grab Rotating Light Duty Multipurpose Grab Excavator Grab Rotating Light Duty Multipurpose Grab Excavator Grab Rotating Light Duty Multipurpose Grab
